AHTS Barge, 57,9m, 24 persons, Charter, rebuilt 2018, Ref C3537
57.9m AHTS For Charter
Date Launched: 1999
Length: 57.90m (189ft 11in)
Beam: 15m (49ft 2in)
Draft: 3.80m (12ft 5in)
Built: 1999, Japan
Hull material: Steel
Flag: Norway
Class Society and Notation: DNV 1A1 Tug SF E0 DYNPOSAUT DK
Next DD: October 2021
Next SS: July 2024
Next Annual Survey: October 2022
PRINCIPLE DIMENSIONS
Length Overall: 57.90m
Breadth: 15m
Depth: 5.50m
Draft: 3.80m
MACHINERY & PROPULSION
Total power output: 5440 bhp
Main Engine: 2 x Bergens KRMB-9
Main Propulsion System: Twin Screw
Auxiliary engine: 2 X 360 KW , Scania
Propellers: 2
Speed maximum: 13.5 knots
Speed cruising: 9 knots
ADDITIONAL INFORMATION
Rebuilding 2018
Deck area 372 m 2
Tonnage: 1368 t
Bollard pull 66 TBP
Deck crane Z Marine, 25 Te capacity at 22 m
Aux deck crane AKC 145 HE4, 9 Te at 11 m
Deck capacity 5 Te/m 2 , 10 Te/m 2 at stern
Propulsion: 2 x CPP Rolls Royce 600 AGSC KP/500 ND
Bow thrusters: 2 x 700 bhp, 8.25 Te thrust each
Stern thruster: 1 x 700 bhp, 8.25 Te thrust
Fuel oil pumps80m3/h
Freshwater pumps 100 m 3 /h
FiFi set Diesel driven 600 m 3 /h
FiFi monitors 2 x 300 m 3 /h, water/foam
TANK CAPACITIES
Fuel oil 406 m 3
Freshwater 470 m 3
DECK EQUIPMENT
Towing / AH winch 150 Te pull / 250 Te brake with two drums and capacity of 1400 m wire 56 mm.
Tugger winches 2 off winches 5 Te pull 1 off winch 20 Te pull
Storage drum 1 x wire
Shark jaws 2 x Karm forks
Smith towing bracket 200 Te SWL at forecastle
Chain gypsy 2 x for Ø = 76 mm chain
Capstan 2 x 10 Te
Rig chain lockers 2 x 53 m 3
Stern roller Ø = 2 m, L = 4 m
Fast Rescue Craft MP660 Springer
ACCOMMODATION
Air-conditioned accommodation for 24 persons including vessel crew.
Client cabins, meeting rooms and facilities for coordinating projects.
Large deck with crane reach to stern roller and wood protection for safe and efficient load-out, sea fastening
