RO-RO/Cargo, LOA 132, 111, TRAILERS, DWT 7200, 1983, Ref C3652

M/V TBN 1 - DIRECT WITH OWNERS
===============================
TYPE: RO-RO CARGO, 3 DECKS
DOUBLE BOTTOM
DWT 7200 MTS ON 6,18M DRFT
BLT 83 DENMARK
TL
LOA 132 BEAM 20,12M, DEPTH 11,6M
LANE METERS 1497 TTL, TRAILERS 111
M/E MAK 12M453AK, BHP 4890 TOTAL
SPEED 10/14,5KNOTS
GENS: 1 (SHAFT),3

BUILDER FREDERIKSHAVN DENMARK
HULL NO 408
DATE KEEL LAID 01/12/1983
DATE LAUNCHING 24/02/1984
DATE OFFICIAL SEA TRIAL 01/07/1984
DATE DELIVERY 01/06/1984
MAX. HIGH (At Summer Draft) 33.00 METERS
EX-NAME MERCANDIAN DUKE , CANARIAS EXPRESS
LINE MTERS(TRAILER)
LINE MTERS(CARS(1,70 m))
UPPER DECK (h x square) m x 1850 m2 (4 meter only down of wheelhouse)
MAIN DECK (h x square) 4,4 m x 1750 m2
LOWER DECK (h x square) 3,9 m x 899 m2
PLATFORM DECK (h x square)
LUB OIL CAPASITY 20,82 m3 & 14,6 tons
F/W CAPACITY (1,0) 104,8 m3 & 104,8 tons
BALAST CAPACITY (1,025) 1835,1 m3 & 1881,1 tons
DIESEL OIL CAPACITY (0,84) 125 m3 & 105 tons
FUEL OIL CAPACITY (0,91) 521,8 m3 & 474,8 tons
HEELING TANKS CAPACITY 527,9 m3 & 527,9 tons
PERSON(MAX. CREW) 28 PERSONS
MIN.SAF.MANING 10 CREW
LIFE BOAT CAP. 2 x 28
LIFE RAFT CAP. 2 x 16 + 1 x 6
LIFE BUOY 10 PCS
LIFE JACKET 32 PCS + 3 PCS(CHILDREN)
FIRE EXTINGUISHERS FIXED HIGH PRESSURE CO2
P&I INSURANCE RAETS
H&M INSURANCE ANADOLU SIGORTA
SPEED 10 KNTS
MAIN ENGINE MAK 12M 453 AK 356KW - 50159
PROPELLER PITCH PROPELLER
ANCHOR 540 KG X 2
CHAIN (STB) 8 SHACKLES
CHAIN (PORT) 8 SHACKLES
STERN DOOR
STERN RAMP (L x B x h ) 14,0 x 7,7 x 5,0 m

Inspection can be arranged
Charter
Ref C3652
Charter

Regards Keith
UK office 0044(0)1342 459089
Mobile 0044(0) 7885775317
www.Yachts-Global.com
commercial@yachts-global.com
Skype yachtsglobal

Year: 1983
Vessel Location: med
Telephone: 0044(0)1342 459089
Mobile: 0044(0) 7885775317
E-mail Seller: Click here
